Material:
Spherical Head Lifting anchors are available in following material
| Liftings |
Material |
Material Type |
Standarad |
| ESB, ESBB, ESE |
S355J2 |
Electro Zinced |
EN 10025 |
| ESB, ESBBs, ESEs |
1.4301 |
Stainless Steel |
EN 10088 |
| ESBa, ESBBa, ESEa |
1.4401 |
Acid Resistant Steel |
EN 10088 |
Components Recommendation:
Pipe, Slab, Wall, Beam, Column, Balcony, Foundation, Manhole
Colour Coding System:
A colour coding system for different diameters of lifting insert is used for easy identification.
Colour Codes For Spherical Head Lifting System
| Load Group (t) |
Colour |
| 1.3 |
Pale Green |
| 2.5 |
Light Coral |
| 4.0 |
Baby Blue |
| 5.0 |
Plum |
| 7.5 |
Khaki |
| Load Group (t) |
Colour |
| 10.0 |
Lucky Orange |
| 15.0 |
Antique Steel |
| 20.0 |
Burly Wood |
| 32.0 |
Steel Blue |
| Colour Code |
Pale Green |
Load Group |
1.3t |
| Size |
1.3-40 |
1.3-50 |
1.3-65 |
1.3-85 |
1.3-120 |
1.3-204 |
| H(mm) |
40 |
50 |
65 |
85 |
120 |
240 |
| D1(mm) |
18 |
18 |
18 |
18 |
18 |
18 |
| D2(mm) |
25 |
25 |
25 |
25 |
25 |
25 |
| d(mm) |
10 |
10 |
10 |
10 |
10 |
10 |
| Colour Code |
Light Coral |
Load Group |
2.5t |
| Size |
2.5-55 |
2.5-65 |
2.5-85 |
2.5-120 |
2.5-170 |
2.5-180 |
| H(mm) |
55 |
65 |
85 |
120 |
170 |
280 |
| D1(mm) |
25 |
25 |
25 |
25 |
25 |
25 |
| D2(mm) |
35 |
35 |
35 |
35 |
35 |
35 |
| d(mm) |
14 |
14 |
14 |
14 |
14 |
14 |
| Colour Code |
Baby Blue |
Load Group |
4.0t |
| Size |
4.0-75 |
4.0-100 |
4.0-120 |
4.0-170 |
4.0-210 |
4.0-340 |
| H(mm) |
75 |
100 |
120 |
170 |
210 |
340 |
| D1(mm) |
36 |
36 |
36 |
36 |
36 |
36 |
| D2(mm) |
45 |
45 |
45 |
45 |
45 |
45 |
| d(mm) |
18 |
18 |
18 |
18 |
18 |
18 |
| Colour Code |
Plum |
Load Group |
5.0t |
| Size |
5.0-85 |
5.0-95 |
5.0-120 |
5.0-180 |
5.0-240 |
5.0-340 |
5.0-480 |
| H(mm) |
85 |
95 |
120 |
180 |
240 |
340 |
480 |
| D1(mm) |
36 |
36 |
36 |
36 |
36 |
36 |
36 |
| D2(mm) |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
| d(mm) |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
| Colour Code |
Khaki |
Load Group |
7.5t |
| Size |
7.5-100 |
7.5-120 |
7.5-140 |
7.5-165 |
7.5-200 |
7.5-300 |
7.5-540 |
| H(mm) |
100 |
120 |
140 |
165 |
200 |
300 |
540 |
| D1(mm) |
46 |
46 |
46 |
46 |
46 |
46 |
46 |
| D2(mm) |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
| d(mm) |
24 |
24 |
24 |
24 |
24 |
24 |
24 |
| Colour Code |
Lucky Orange |
Load Group |
10.0t |
| Size |
10.0-115 |
10.0-135 |
10.0-150 |
10.0-170 |
10.0-250 |
10.0-340 |
10.0-680 |
| H(mm) |
115 |
135 |
150 |
170 |
250 |
340 |
680 |
| D1(mm) |
46 |
46 |
46 |
46 |
46 |
46 |
46 |
| D2(mm) |
70 |
70 |
70 |
70 |
70 |
70 |
70 |
| d(mm) |
28 |
28 |
28 |
28 |
28 |
28 |
28 |
| Colour Code |
Antique Steel |
Load Group |
15.0t |
| Size |
15.0-140 |
15.0-165 |
15.0-200 |
15.0-300 |
15.0-400 |
15.0-840 |
| H(mm) |
140 |
165 |
200 |
300 |
400 |
840 |
| D1(mm) |
69 |
69 |
69 |
69 |
69 |
69 |
| D2(mm) |
85 |
85 |
85 |
85 |
85 |
85 |
| d(mm) |
34 |
34 |
34 |
34 |
34 |
34 |
| Colour Code |
Burly Wood |
Load Group |
20.0t |
| Size |
20.0-200 |
20.0-240 |
20.0-250 |
20.0-340 |
20.0-500 |
20.0-1000 |
| H(mm) |
200 |
240 |
250 |
340 |
500 |
1000 |
| D1(mm) |
69 |
69 |
69 |
69 |
69 |
69 |
| D2(mm) |
98 |
98 |
98 |
98 |
98 |
98 |
| d(mm) |
38 |
38 |
38 |
38 |
38 |
38 |
| Colour Code |
Steel Blue |
Load Group |
32.0t |
| Size |
32.0-320 |
32.0-700 |
32.0-1200 |
| H(mm) |
320 |
700 |
1200 |
| D1(mm) |
88 |
88 |
88 |
| D2(mm) |
135 |
135 |
135 |
| d(mm) |
50 |
50 |
50 |
